Last fall, LUMIX announced its new full frame cameras, the S1 and S1R, which will feature a new L-Mount lens collaboration between LUMIX, Leica and Sigma. Early this morning, LUMIX came out with more information about both cameras. Let me give you the big details up front, and you can read the entire release below.
S1R, 47.3 megapixels
Boasting a full 36x24mm sensor, the S1R offers the highest resolution of any full-frame mirrorless camera on the market. Plus, the high-resolution mode — which combines multiple frames into a single raw file — turns out a 187 megapixel image. Are you going to need a new computer to handle the big files?
The max ISO is 25,600, and the new Venus processor ensures a low noise image. I’m excited to see how well this performs.
S1, 24.2 megapixels
Interestingly, the sensor is slightly smaller than the S1R at 35.6×23.8mm, but it really doesn’t matter and it won’t make your pictures any better or worse 🙂 The S1’s high-resolution mode puts out a 96 megapixel raw file. Also, the new high-resolution modes can handle moving objects in the frame.
The max ISO is 51,200, and it also uses the new Venus Engine. Dynamic range should be magnificent.
Both cameras can make videos at 4K/60p, and they’ll do 4K/30p at 4:2:2 10 bit. They have HDMI outputs so you can view your work on big monitors or TV’s. Vlog will be available later in 2019 as an upgrade purchase.
Triaxial tilt screen
Sorry, but you can’t flip the screen all the way forward to see your self for your vlogging adventures. But why would you use a camera of this caliber for vlogging, anyway? The screen lets you see it from all angles if you use the camera as a normal operator.
The new Venus Engine is also applied to the autofocus for the fastest AF in the industry (their words). They’ve also applied AI to the focus so that it recognizes subjects and tracks them better than ever before. These cameras are also capable of -6EV focusing, which means it can be pretty dark or your subject can be backlit and it’ll still focus accurately.
In-Body Image Stabilization (IBIS) and lens stabilization are both improved. There’s 5-axis stabilization in the body, and 2-axis in the lenses.
This is especially good for photographers: The max shutter speed is 1/8000s, and the max flash sync speed is 1/320s. That’s the fastest flash sync speed on this size sensor in the industry, and it gives you another bump toward overcoming the brightness of the sun without overpowering your flash.
Is this for you?
This camera is a significant evolution for mirrorless cameras, and especially since it’s building on LUMIX’s more than decade-long experience building mirrorless cameras. If you need a full-frame camera, this looks to be a very good one. The S1 is now available for pre-order for $2497.99, while the S1R runs $3697.99. You can get your pre-order in today, along with lenses and other accessories. For more information, see the full press release below.
Press release: Panasonic launches new Lumix S Series full-frame mirrorless cameras — LUMIX S1R and LUMIX S1
After the development announcement at Photokina 2018, Panasonic is now proud to introduce the full specifications of its long-awaited first full-frame Digital Single Lens Mirrorless cameras, the LUMIX S1R and S1, with a 35mm full-frame CMOS sensor. The new cameras are based on the L-Mount standard, which boasts a well-balanced, large inner diameter and compact dimensions for a flange focus to realize optimum size and performance as a mirrorless camera system.
The LUMIX S Series aims for unprecedented image quality with high resolution, rich gradation and superior color reproduction. A high-speed, high-precision AF system based on advanced control technology over the lens, the sensor, and the new Venus Engine enable the user to capture the target in sharp focus without fail. The LUMIX S Series also boasts industry-leading video recording performance (4K 60p/50p), intuitive control, a rugged design for heavy field use, durability, and expandability.
The LUMIX S1R integrates a 47.3-megapixel full-frame CMOS sensor (36mm x 24mm), which gives it the industry’s highest level of resolution in the full-frame mirrorless cameras, to pursue the ultimate power of expression. In addition to the precise reproduction capability in detail, this sensor achieves a high S/N ratio by taking advantage of its high light-condensing efficiency despite the large number of pixels. The LUMIX S1R features a High Resolution mode for the first time as a mirrorless full-frame camera to enable 187-megapixel ultra-high precision photo shooting.
The LUMIX S1 comes with a 24.2-megapixel full-frame CMOS sensor (35.6mm x 23.8mm) that provides a wide dynamic range and excellent performance at high sensitivity in addition to a natural yet sharp image description thanks to sufficient light condensation per pixel. The LUMIX S1 supports professional use in videography by taking advantage of the stunning expression performance that a full-frame camera can offer. It records smooth 4K 60p/50p video and enables full-pixel readout of signals in 4K 30p/25p to save truly beautiful footage. Furthermore, the LUMIX S1 will comply with 4:2:2 10-bit 4K 30p/25p internal video recording and 4K 60p/50p HDMI output as well as V-Log, with a software upgrade key (to be sold separately) following soon in 2019.
Panasonic’s advanced Contrast AF system with DFD technology has evolved through the development of numerous mirrorless cameras to make the AF system of the LUMIX S1R/S1 even more practical. It achieves not only the industry’s fastest level of focusing speed but also a tracking performance that is made possible by the adoption of Advanced AI Technology that accurately recognizes moving target subjects. The LUMIX S1R/S1 incorporates a Body I.S. (Image Stabilizer) to effectively compensate for the hand-shake movement. Combining the Body I.S.(5-axis) and the O.I.S. (Optical Image Stabilizer, 2-axis) in the LUMIX S Series lenses, the Dual I.S. 2 boasts even more powerful compensates for virtually any types of blur. Equipped with a high-resolution Real View Finder, triaxial tilt rear monitor and high performance shutter unit with high durability, the rugged design LUMIX S1R/S1 provides the professional photographers with high reliability.
Drawing on the vast expertise of the L-Mount Alliance with Leica Camera and Sigma, various interchangeable lenses are available for the LUMIX S Series. On the other hand, the LUMIX PRO service has also launched to support professional work globally.
As a pioneer of the Digital Single Lens Mirrorless camera, Panasonic has pursued innovations in technology under the vision of “Changing Photography”. Crystallizing all these digital and optical technologies, Panasonic is committed to introducing an unparalleled full-frame camera system without compromise for professional photographers and videographers.
High picture quality made possible by the first LUMIX full-frame mirrorless camera Unprecedented picture quality and high descriptive performance
The LUMIX S1R incorporates a new 47.3-megapixel CMOS sensor without LPF (Low Pass Filter) to realize high resolution and descriptive performance. This sensor adopts an aspherical lens for the on-chip micro lens to enhance light condensation. Together with the optimum design to concentrate more incoming light onto the photodiode, it achieves both high resolution and highly efficient light condensation performance. This results in the realization of the industry’s highest level of 47.3-megapixel resolution in the full-frame mirrorless cameras at high S/N ratio and maximum ISO 25600 high sensitivity. The large amount of digital signals is processed by the new high-speed, high-performance image processor Venus Engine to render images with breathtaking description in both photo and video.
The LUMIX S1 employs a 24.2-megapixel CMOS sensor. The new Venus Engine, which is exclusively tuned for the full-frame camera, and its Multipixel Luminance Generation and Intelligent Detail Processing realize natural, high-resolution expression while suppressing color moiré. Three-dimensional Color Control improves the color reproduction of both bright and shadow areas. This results in natural, true-to-life images from low to high sensitivity. Taking advantage of sufficient light condensation, the LUMIX S1 boasts a wide dynamic range and reproduces sharp images with exceptional clarity. Noise is minimized even when shot at maximum ISO 51200 high sensitivity. It is an ideal camera to use especially in low-light situations.
An AR coating applied on the sensor of both LUMIX S1R/S1 minimizes ghost and flare even in backlighting. Combination with the high-quality LUMIX S Series lenses based on the L-Mount further enhances the potential of the camera.
Plus, the LUMIX S1R/S1 integrates the Body I.S. (Image Stabilizer) for powerful handshake correction. Panasonic developed an algorithm that precisely calculates shake information acquired not only from a gyrosensor, but also from the image sensor and accelerometer sensor. This enables more accurate shake detection and compensation, making it possible to use a 5.5-stop slower shutter speed. Combining the Body I.S. (5-axis) in the camera and the O.I.S. (Optical Image Stabilizer, 2-axis) in the LUMIX S Series lens, the 5-axis Dual I.S. 2 compensates for larger movements that were conventionally uncontrollable. Maximizing both O.I.S and B.I.S. is highly beneficial in telephoto shots and in adverse situations, such as in low-light or with one-handed shooting with a 6-stop slower shutter speed. The 5-axis Dual I.S. 2 works for both photo and video recording, including 4K. The Body I.S. compensates for camera movement even when other L-Mount lenses without O.I.S. are used.
Taking full advantage of its high-resolution sensor, the LUMIX S1R/S1 provides a High Resolution mode that faithfully reproduces precise details to be saved as beautiful, highly realistic RAW images. Eight consecutive images are automatically shot while shifting the sensor using the Body I.S. (Image Stabilizer) mechanism and synthesized into a 187-megapixel equivalent (16,736 x 11,168-pixel) image for LUMIX S1R and 96-megapixel equivalent (12,000 x 8,000-pixel) image for LUMIX S1 by the new Venus Engine, which boasts high-speed signal processing. This mode is suitable for taking natural landscapes or fine arts with delicate details. This magnificently high resolution photo is ideal for landscape photography of stationary subjects using a tripod. However, it can also be used in situations where moving subjects are included in the scene, by switching the sub mode.
The HLG Photo mode is a whole new style of photo expression that Panasonic proposes. It provides a wider dynamic range to reproduce light and shadow with more natural contrast. The HLG Photos can also be produced as an HSP file with compressed high-brightness signals in stunning 8K resolution (7,680 x 4,320 in 16:9, with LUMIX S1R) or its full resolution (5,888 x 3,312, in 16:9, with LUMIX S1) in addition to JPEG/RAW files. It excels in the expression of lights, such as sparkling starlight or glaring sunlight. The user can playback these vibrant images on the latest Panasonic HLG-compliant 4KTV via HDMI cable connection or other HLG-compliant devices. It is also ideal for photo presentations by photographers.
The high-precision shutter unit offers the highest shutter speed at a maximum 1/8000 second to capture spur-of-the-moment, fast moving subjects and to use a high-speed lens with a fully open aperture even outdoors for impressive defocusing. The external flash can be synchronized with the industry’s fastest shutter speed of a maximum 1/320 second.
High-speed, high-precision AF system
Panasonic has achieved a high-speed AF with its advanced control technology over the major devices – lens, sensor and imaging engine. The lens and sensor communicate at a maximum 480 fps. Combining the Contrast AF with DFD technology, the LUMIX S1R/S1 realizes an ultra high-speed, high-precision AF of approximately 0.08 sec. The LUMIX S1R/S1 also boasts high speed burst shooting at 9 fps (AFS) or 6 fps (AFC). With its high subject tracking performance, the LUMIX S1R/S1 never loses the target subject. As a camera that excels in low-light shooting, the LUMIX S1R/S1 boasts -6EV luminance detection performance with Low Light AF thanks to the higher sensitivity and optimized tuning of the sensor. The face/eye detection technology makes it possible to capture people in crisp focus, the Eye AF even detects the pupil of the eye and precisely focuses on it for impressive portrait shooting. The LUMIX S1R/S1 also incorporates Advanced AI Technology that detects specific subjects – humans and fast-moving animals, including canidae, felidae and birds. The camera keeps tracking these subjects even when they turn their back to the camera.
For more continuous burst shooting, 6K PHOTO makes it possible to capture unmissable moments at 30 fps by extracting the frame with the best timing out of a 6K burst file (in 4:3 or 3:2 aspect ratio) to save as an approximate 18-megapixel equivalent high resolution photo. The 4K PHOTO enables 60-fps high-speed captures in approximate 8-megapixel equivalent resolution. In 6K PHOTO /4K PHOTO, three exclusive modes can be chosen from depending on the situation; 6K Burst/4K Burst, 6K Burst (Start/Stop)/4K Burst (Start/Stop) and 6K Pre-burst/4K Pre-burst. Users can choose the most suitable burst shooting mode in addition to the regular consecutive shooting mode in full resolution depending on the situation.
Operability from ingenuity for intuitive control
The LVF (Live View Finder) is the key factor for completing the ultra high-speed response of the camera. The LUMIX S1R/S1 has the largest level of Real View Finder which boasts the world’s highest 5,760k-dot resolution. The 0.78x magnification ratio can be switched to 0.7x or 0.74x according to the shooting situation. Adoption of a high-speed, high-precision OLED (Organic Light-Emitting Diode) for the LVF achieves smooth display at 60 fps/120 fps (switchable) and high-speed response with minimum time lag of less than 0.005 sec as well as 10,000:1 high contrast for exceptional visibility. With minimum distortion and high optical performance, this Real View Finder provides a natural view as seen with the naked eye. It is always sharp and clear from the center all the way to the corners.
The 2,100K-dot high resolution monitor in 3:2 aspect ratio has adopted a triaxial tilt moving element to secure both durability and operational ease. It also has a touch control system. Live View Boost is another practical feature that makes it possible to check the composition even in total darkness by boosting the sensitivity just for live view. It also incorporates a Night mode that provides mild backlighting. It lets the user watch the subject comfortably even right after viewing the monitor while in a dark situation for a long time. The LUMIX S1R/S1 includes a largest-in-class Status LCD on the top, allowing users to check the settings at a glance.
To make the camera just like a part of the photographer’s body, the LUMIX S1R/S1 provides a firm grip, making it easy to hold for long periods. The control buttons and dials are located based on an ergonomic study to enable the user to concentrate on shooting. The adoption of an 8-directional joystick and refined UI (User Interface) also supports quick operation during shooting. In addition, illuminated buttons can be of help in low-light situations. An operation lock lever prevents unintentional operation, and the user can choose which operation to lock.
Rugged design, reliability and expandability
To be tough enough to withstand heavy field use, the main structure is composed of a magnesium alloy full die-cast front/rear frame. Robust construction and a sealing for every joint, dial, and button make the LUMIX S1R/S1 not only splash resistant and dust resistant but also freeze resistant down to -10 degrees Centigrade. The shutter unit is also durable for approximately 400,000 cycles.
The LUMIX S1R/S1 is equipped with a double Memory Card slot compatible with SD (UHS-II) or XQD Memory Cards for high-speed, high-capacity continuous data recording. Users can flexibly choose the recording method from Relay Recording, Backup Recording or Allocation Recording using the double slots. It will also be compatible with CFexpress in the near future. The 7.4-V 3,050 mAh high-capacity battery can be quickly charged via USB PD (USB Power Delivery) using the bundled USB3.1 Type-C cable. And it also realizes high-speed data transfer.
A variety of new accessories are available for the LUMIX S1R/S1 including Remote Shutter (DMW-RS2), Eyecup (DMW-EC6), Battery Grip (DMW-BGS1) and Battery Charger (DMW-BTC14). The Battery Charger also complies with USB PD and enables quick power charging in approximately 2 hours. The camera can be used while charging via this adaptor. The conventional External Flash (DMW-FL580L / FL360L / FL200L) can also be mounted on the LUMIX S Series cameras.
Outstanding video recording performance in a full-frame camera
LUMIX S1R: 4K 60p/50p video recording for more creative freedom
The LUMIX S1R is a camera designed and developed to boast exceptional performance in photography, yet is capable of 4K 60p/50p video recording. To elevate the video expression even more, a variety of effects are available for video recording.
LUMIX S1: Exceptional video recording performance for professional videographer
The LUMIX S1 features outstanding video performance for professional videography with 4K 60p/50p recording. It realizes a crop factor of 1.0x in 4K 30p/25p/24p, which means that the user can record video in the original viewing angle of the lens. There is no recording time limit for both 4K 30p/25p/24p and Full-HD video. Notably, the CMOS Sensor with high sensitivity on the LUMIX S1 achieves full-pixel readout for an excellent S/N ratio. The HDR (High Dynamic Range) video recording is available, which reproduces both the bright parts and dark parts of an image, making it look just like human eyes see it. The camera records video with a designated gamma curve compatible with ITU-R BT.2100, and you can now choose Hybrid Log Gamma (HLG) in Photo Style. The LUMIX S1 further expands its potential with a firmware update including 4:2:2 10-bit 4K 30p/25p internal video recording and 4K 60p/50p HDMI output as well as V-Log, with a Software Upgrade Key (to be sold separately) following soon in 2019.
As a camera from Panasonic that has been overstepping the limit of video performance in digital cameras, a host of functions are available on the LUMIX S1R/S1. The High Speed Video lets users record slow motion video in 4K (maximum 60 fps/ 50 fps) and FHD (maximum 180 fps /150 fps).
For the terminal, an HDMI Type A is provided. Plus, a cable lock holder for the HDMI cable is included in the LUMIX S1R/S1 to prevent unplugging trouble on location. LINE input is also supported by a 3.5-mm microphone jack. This makes it possible to input sounds from an external audio device, for more efficient video production. A 3.5-mm headphone jack is also available. In addition, it complies with the Microphone Adaptor DMW-XLR1 (sold separately), which is a plug-in type adaptor for an XLR microphone to record high-quality stereo sound. It is ideal for lip-sync recording. Dedicated switches allow direct, quick control. MIC, LINE and CONDENSER MICROPHONES are switchable.
Photo Style featuring a new Flat mode: To shorten post-processing work, JPEG photos can be adjusted precisely according to the photographer’s intention. The LUMIX S1R/S1 also provides a Flat mode that features a plain finish with less contrast and saturation for versatile use.
Variable aspect ratios with new 65:24 and 2:1: In addition to the standard 3:2, 4:3,16:9 and 1:1, 65:24 (Film Panorama) and 2:1 (6 x 12 cm) aspect ratios are available for photo shooting.
I.S. Status Scope: The user can consciously remove the cause of shake by checking a pointer that indicates the camera’s shaking condition. It is available while the viewfinder or rear monitor blacks out even during a long-time exposure.
Flicker Decrease: When the flickering of a fluorescent light is detected, the camera indicates it and releases the shutter when its effect is the least to suppress the discontinuity of exposure or color across a sequence of photos.Not available in 6K PHOTO, 4K PHOTO and Post Focus.
Highlight Weighted Light Metering Mode: The Highlight Weighted Light Metering Mode meters light with the priority on highlighted parts, to prevent it from washing out.
New AWBw Auto White Balance mode: In Auto White Balance, a new AWBw that retains a reddish tint is available in addition to conventional AWB (standard) and AWBc (bluish tint). AWBw reproduces healthy, rosy skin color even under fluorescent light.
Bluetooth 4.2 and Wi-Fi 5GHz (IEEE802.11ac) / 2.4GHz (IEEE802.11b/g/n): Compatibility with Bluetooth 4.2 (called BLE: Bluetooth Low Energy) enables constant connection with a smartphone/tablet with minimum power consumption. The settings of a LUMIX S1R/S1 camera can also be copied and transmitted wirelessly to other S1R/S1 cameras when using multiple S1R/S1 cameras. Also, Wi-Fi 5GHz (IEEE802.11ac) is effective in addition to 2.4GHz (IEEE802.11b/g/n.) This provides even secure and stable connection not only with a smartphone/tablet but also with other devices on location for smooth remote control. Transmission speed of photo/video data is also increased up by using the 5GHz-band.
Lumix Tether: This software enables tethered shooting via USB. Users can control the camera by connecting it to a PC via USB. It lets you view the image on a large PC screen while shooting, which is helpful in commercial photoshoots of portraits, products and so on, where continuous confirmation is required. You can use [6K PHOTO] [4K PHOTO] and start and stop video recording with tethered shooting. It is also possible to choose the folder to save the image files in the PC.
Lumix Sync: Lumix Sync is a new application for iOS/Android devices, which enables photo transmission to a smartphone or tablet via easy wireless connection. It also allows remote control of the camera using a smartphone or tablet.
