If you’re shopping for a DSLR or mirror less camera this season, you may hear the terms cropped or full-frame sensor pop up.  Essentially, these are describing the size of the sensor within the camera. Full frame sensors are generally only found on cameras considered for pros, while cropped sensors are most common and can appear throughout product lines.

sensor

Digital sensor sizes vary greatly between camera models and manufacturers. This is why the 35mm frame from a traditional film camera is used as a standard for comparison.  This is often referred to as ‘full frame’ size. Although a full-frame sensor is often held up as a gold standard, many affordable cropped sensor cameras are on the market that also perform well.

A full frame sensor produces an image like this.

A full frame sensor produces an image like this.

When using a pro lens (one that doesn’t compensate for the cropped sensor) the smaller sensor can only show a smaller area of the scene. Nikon labels these lenses DX (which are often more affordable and design for cropped sensors) and FX which are for full frame sensors. The effect of a cropped sensor is that it effectively multiplies the range of a lens.

Using a cropped sensor, the image is magnified

Using a cropped sensor, the image appears “magnified” or cropped.

For example, if you put a 50mm lens on a full frame camera, it will act as marked. But if you put that 50mm lens on a body with a cropped sensor, the effective focal range is multiplied due to the smaller sensor size. On many Nikon cameras, the crop factor of 1.5 will make the 50mm lens behave as if it is a 75mm lens. This is often referred to as the effective focal length.

The following crop factors are common:

  • 1.3x – This is used on some pro Canon EOS cameras.
  • 1.5x  This crop factor is employed by Nikon for most DX lineup, like the D7000 and D3100.
  • 1.6x This crop factor is used by Canon for its APS-C bodies, like the 7D
  • 2.0x – Many MFT cameras like Olympus and Panasonic use this.

The cropped sensor has a few benefits that some users prefer:

  • Less cost than full frame lenses and bodies.
  • Less weight in general
  • Ability to get tighter coverage, especially if combined with a teleconverter.

On the downside, possible negatives include:

  • Less range in depth of field
  • Additional math if you’re used to use the mm rating on lenses
  • Low light performance is reduced.

I routinely find myself using both cropped and full frame sensors.  My Nikon D600 is a full frame, while my D7000 is cropped.  I also use a few Canon models that are cropped and my Olympus, Blackmagic, and Panasonic cameras all use cropped sensors.

The take-away… don’t believe the hype.  There are as many good reasons to shoot on either sensor type as there are drawbacks.

Sound of in the comments below about your preferences and why.

______

This Post Sponsored by:

Adobe Photoshop CC and Lightroom for US$9.99/mo. Limited-time offer for Photoshop CS3 and later customers. Get it here. Be sure to also check out the Video for Photographers learning center.

The HDR Learning Center Check out new ways to use High Dynamic Range photography to make compelling images. Free tutorials and posts to get results. Produced in partnership with HDRsoft.

Mosaic A complete solution for photographers using Lightroom who want to manage and share their photos. You can easily view images with their iOS app or web service. Plus your photos are backed up to the cloud with several plans to match your needs.

lynda.com Learn photography anytime, anywhere, and at your own pace—from bite-sized tutorials to comprehensive courses. Try lynda.com free for 10 days by visiting lynda.com/ Photofocus.

The Topaz Labs Image Enhancement bundle. Open up a world of creative possibilities with a seamless, integrated workflow. You don’t need to be a Photoshop wizard to look like one. Click here and use the code photofocus to get a 15% discount.

Join the conversation! 7 Comments

  1. A 50mm lens with a crop factor of 1.5 has the same field of view as a 75mm lens on a full frame sensor. I think you’ll find that the perspective is quite different. The 50mm lens on a crop sensor yields the same perspective as a 50mm lens on a full frame sensor as your example images show.

    Reply
    • The demo image is a simulation by swapping mode on camera. But yes, effective focal length is different than field of view.

      Reply
    • I am going to pick nits and say that the perspective is the same, but the field of view is different. The image is literally just cropped; there is no change in the angle of view (or relationship between foreground and background objects).

      Reply
      • You are absolutely correct in saying the image is literally just cropped. That is the same as saying the field of view is narrower. The perspective or sense of compression of objects is totally different in lenses of different focal lengths.

        Reply
  2. Good description as always. This whole “cropped” discussion assumes the fact that the old 35mm frame was optimal for everything. Having grown up with 35mm, I know that in those days the 35mm was considered “cropped” by “professional” photographers.

    The ultimate question is NOT sensor size… It is “do you get the quality of image that you WANT in the package you can carry or can afford.” Answer that and you’ve given me value.

    Reply
  3. I’ve resisted the temptation to go FF from my D7000.

    Maybe cameras like the A7/A7R will stimulate a move towards smaller FF designs (as well as integration of connectivity).

    Then it might be worth checking out the format.

    Reply
  4. Lots of pedantry here – not sure how it actually helps photographers.

    Reply
